M3 OX10 - 1G RFID
Fully Rugged Industrial PDA
  • - 1 GHz
    - Windows Embedded Handheld 6.5/ Windows Embedded CE 6.0
    - 1D / 2D / RFID
    - HF(13.56MHz), UHF(868~956MHz) RFID
    - 5.0M Pixels Auto Focus Camera
    - Bluetooth Class II, V2.1 with EDR
    - WLAN IEEE 802.11 a/b/g/n
    - Smart Battery

  • tabbutton1

    • Windows Embedded Handheld 6.5
      Windows Embedded Handheld 6.5 operating system which is familiar to handheld computer users ensuring easy integration and intuitive operation.
    • 1GHz
      Powerful CPU speed with "High-Tier" guarantees faster graphic process and memory access.
    • 1D, 2D, RFID
      Superior scanner/imager application provides real-time data capture and automatic data processing so that you can expect flexibility of work and cost efficiency.
    • 5.0M Pixels AF Camera
      High resolution and auto focused functionality capture clear images of product and/or documentation.
    • Multi-function QWERTY keypad
      Multi functional keys of QWERTY keypad are designed for versatile performance. As hot keys, these are going to make the direct access be possible and increase user's working speed.



    • Smart Battery (Li-Ion 3.7V 3,300mA)
      M3 OX10 Family's smart battery provides accurate remaining battery capacity so that the user can efficiently plan the usage of the PDA. Also, is large capacity is suitable for long time shifts
    • Slim & Light
      M3 OX10 Family is a slim and light but rugged. It can be used for ticketing and/or asset management wherever the mobile device is needed.
    • Endurance for temperature
      M3 OX10 Family can be operated within -20 degree to 60 degree and its storage temperature is -30 degree to 70 degree. It will guarantee the normal function at any temperature of working environment.
    • IP 65 Sealing, 1.5m Drop
      M3 OX10 Family is suitable to use in a tough environment withstands drops from 1.5m and protects against dust and water.
    • Solutions
      Terminal Emulation : Wavelink, Softogo, Naurtech
      Mobile Management : SAP, Wavelink, Soti
  • tabbutton1

      Физические характеристики
      Размер (ШхВхГ)
      Миллиметры 78.6 x 165.5 x 24.9
      78.6 x 165.5 x 40.2 (with HF)
      78.6 x 165.5 x 38.9 (with UHF)
      Дюймы 3.1 x 6.5 x 0.9
      3.1 x 6.5 x 1.58 (with HF)
      3.1 x 6.5 x 1.53 (with UHF)
      Вес (ВКЛ. батарея)
      Граммы 332
      362 (with HF)
      389 (with UHF)
      Унции 11.7
      12.7 (with HF)
      13.7 (with UHF)
      ДИСПЛЕЙ
      Размер 3.5"
      Тип VGA TFT LCD / QVGA
      Пикселы 480 X 640 (plus) / 240 x 320
      БАТАРЕЯ
      Тип Smart Battery
      Аккумулятор Lithium-ion
      Питание 3.7 V, 3,300 mA
      эксплуатационные характеристики
      МУЛЬТИ-ПРОЦЕССОР
      ЦПУ 1GHz
      Радио
      ОС
      Windows Embedded Handheld 6.5
      ПАМЯТЬ
      ОПЕРАТИВНАЯ ПАМЯТЬ 512MB
      ПОСТОЯННАЯ ПАМЯТЬ 4GB
      слот Micro SD, up to 32 GB
      интерфейс USB
      Хост 1.1
      Клиент 2.0
      Пользовательская среда
      ТЕМПЕРАТУРА
      Операционный -20 to 60 ℃ / -4 to 140 ℉
      Хранение -30 to 70 ℃ / -22 to 158 ℉
      ВЛАЖНОСТЬ
      93% non-condensing
      Испытание Падения
      1,000 1.6ft./0.5m tumbles (2,000 drops)
      Испытание на падение
      1.5 m / 5 ft
      Рейтинг IP
      IP65
      Варианты Беспроводного Радио
      сеть WWAN
      Сеть 2G
      (GSM / GPRS / EDGE)
      850/900/1800/1900 MHz
      Сеть 3G
      (UMTS/HSPA+)
      800/850/AWS/1900/2100 MHz
      сеть WAN
      Стандарт IEEE 802.11
      Пропускная способность a/b/g/n
      Безопасность WEP, WPA, WPA2, TKIP, AES, EAP-FAST, EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP- TLS, PEAP-MSCHAPv2, LEAP, CCXv4
      БЛЮТУС
      Класс Class II
      Версия 2.1 (with EDR)
      РАДИОЧАСТОТНАЯ ИДЕНТИФИКАЦИЯ
      Частота HF: 13.56 MHz
      UHF: 868 ~ 956 MHz
      Стандарт HF: ISO 14443 A/B, ISO 15693, ISO 18000-3, I-CODE
      UHF: EPC C1 G2
      система GPS
      AGPS, GLONASS
      Основные опции
      СКАНЕР
      1D O
      2D O
      Большая дальность
      КАМЕРА
      Пиксели 3.0 M
      Фокус Auto Focus
      КЛАВИАТУРА
      Буквенно-Цифровой 31 key
      Qwerty 50 key
      Azerty 50 key

      * Содержание этой спецификации было сделано на основе "текущего состояния" продукта, и эта спецификация может быть изменена без предварительного уведомления.
